NEO-T / Silver / Black / Orange / M / L / 720Wh / 1200Wh / 250W 500W 750W
Adventure begins where the road ends. NEO-T is built for explorers—powerful, durable, and ready to conquer any terrain. Whether it's winding forest trails or open countryside, ride with confidence and embrace the journey.
Relaxed yet sporty riding position, designed for both comfort and efficiency. Ideal for daily commuting and long-distance rides, it combines an ergonomic posture with performance-oriented geometry to ensure a comfortable journey without compromising on speed and agility.
| Size (mm) | M | L |
| A. Effective Top Tube | 603.8 | - |
| B. Reach | 396.5 | - |
| C. Head Tube Length | 90 | - |
| D. Crown to Axle | 535 | - |
| E. Fork Rake | 44 | - |
| F. Wheelbase | 1167 | - |
| G. Stack | 606.7 | - |
| H. Bottom Bracket Height | 295 | - |
| I. Chainstay | 496.5 | - |
| J. Saddle Adjustment Height | 72 | - |
| K. Stand Over Height | 745 | - |
| L. Saddle Height Max | 985 | - |
NEO-SNEO-S is designed for thrill-seekers.
|
NEO-UOur NEO-U moves with you—seamlessly navigating the city.
|
NEO-TNEO-T is built for explorers—powerful, durable, and ready to conquer any terrain.
|
|
Frameset |
|||
| Frame | NEOKEY Carbon Fibre Frame | NEOKEY Carbon Fibre Frame | NEOKEY Carbon Fibre Frame |
| Fork | RockShox FS-PSYL-SRC-A1 travel 140mm | RockShox FS-PSYL-SRC-A1 travel 140mm | RockShox FS-PSYL-SRC-A1 travel 140mm |
| Rear Shock | RockShox RS-DLXC-SEL-B1 max travel 40mm | RockShox RS-DLXC-SEL-B1 max travel 40mm | RockShox RS-DLXC-SEL-B1 max travel 40mm |
| Seatpost | NEOKEY Carbon Fibre | NEOKEY Carbon Fibre | NEOKEY Carbon Fibre |
| Motor Cover | NEOKEY Carbon Fibre | NEOKEY Carbon Fibre | NEOKEY Carbon Fibre |
Driveset |
|||
| Motor Power | 250/500/750W | 250/500/750W | 250/500/750W |
| Battery | 720Wh/1200Wh | 720Wh/1200Wh | 720Wh/1200Wh |
| Display | Bafang DPC030 1.9'' | Bafang DPC030 1.9'' | Bafang DPC030 1.9'' |
| Derailleur | SRAM EAGLE 90 T-TYPE | ENVIOLO CVP Automatic | SRAM EAGLE 70 T-TYPE |
| Chain | SRAM T-TYPE 126 LINK | - | SRAM T-TYPE 126 LINK |
| Carbon Belt | - | Gates Carbon Drive CDX | - |
| Charger | Fast Charger 48V4A | Fast Charger 48V4A | Fast Charger 48V4A |
| Front Sprocket | - | Gates 48T CDX | - |
| Rear Sprocket | - | Gates 19T CDX | - |
Cockpit |
|||
| Handlebar & Stem | NEOKEY Carbon Fibre Handlebar & Stem | NEOKEY Carbon Fibre Handlebar & Stem | NEOKEY Carbon Fibre Handlebar & Stem |
| Head Light | NEOKEY | NEOKEY | NEOKEY |
| Tail Light | NEOKEY | NEOKEY | NEOKEY |
| Saddle | Selle Royal | Selle Royal | Selle Royal |
Wheelset |
|||
| Tyres.f | Schwalbe Smart Sam Black 27.5x2.35'' | Schwalbe Super Motor-X Black 27.5x2.4'' | Schwalbe Smart Sam Black 27.5x2.35'' |
| Tyres.r | Schwalbe Smart Sam Black 27.5x2.35'' | Schwalbe Super Motor-X Black 27.5x2.4'' | Schwalbe Smart Sam Black 27.5x2.35'' |
Brakeset |
|||
| Brake Levers | Magura MT5 4 piston, 2 finger aluminum | Magura MT5 4 piston, 2 finger aluminum | Magura MT5 4 piston, 2 finger aluminum |
| Rotor | MDR-P 180mm (6 hole) | MDR-P 180mm (6 hole) | MDR-C 180mm (6 hole) |
Our products aren’t just clean on the outside — they’re engineered with the same level of order and purpose within. Because true craftsmanship doesn’t hide mess, it hides mastery.
Full suspension system delivers a ride so smooth, it feels like gliding. From rugged trails to city streets — conquer every bump, float through every mile.
Engineered for exceptional performance, it ensures extended belt life, maintains optimal tension, and eliminates the need for manual adjustment during installation.
Switch different modes seamlessly - our modular design delivers limitless versatility.
